Waterproof:
1.Adopt air filter device for preventing moisture condensation inside the luminairebalance the pressure difference between internal and external of luminaire;
2.Imported silicon rubber material is adopted for waterproof gasket;
3.Ingress protection IP66.
Configuration:
1.Small and delicacy,easy to hide and invisible;
2.Die-cast aluminum housing,silver gray powder paint with high corrosion resistance ;
3.Clear diffusor adopted imported high transmittance PC material, with anti-UV & anti-aging resistance, to create luminous uniformity and soft effect;
4.According to the GB7000.1 -2015 5.2 requirements of outdoor luminaire, waterproof connector (Nickel-plated brass) is a must to be adopted to fix power cable. anti-pull up and does not easy to loose;
5.Adopted rubber cable which is abided by the GB7000.1-2015 5.2 requirement for outdoor application. the rubber cable is much more durable than PVC using at outdoor application. PVC is fragile easily when used at outdoor.
Installation: Bottom bracket Fixed by the screws, easy for installation.
Control: 16.7 million lighting effects of RGB color changing, achieve synchronization, chasing, flowing light effects, DMX512 compatible.
Application:Suitable for decorative lighting such as square, landscape, facade building, large building, theme park and entertainment areas etc.
Luminaires shape | Square |
---|---|
Glass material | frosted |
LED quantity | 36 |
LED color (single color) | 5000k(WH)、4000k(WN)、2708-2735K、3011-3075K、3 in 1 red green blue (RGB) |
Power input | 24V DC |
Control | Protocol control |
Installation | |
Cables outlet | |
Electricity Way | 直流 |
Way of connecting wires | Parallel power cable,no waterproof connector、Parallel power cable,no waterproof connector, parallel signal cable,no waterproof connector |
Specification of LED | 2835、20mA |
Lamp length | * |
LED Type | OSRAM3 |
