Waterproof:
1.Adopt air filter device for preventing moisture condensation inside the luminaire. balance the pressure difference between internal and external of luminaire;
2.Imported silicon rubber material is adopted for waterproof gasket;
3.Ingress protection IP66.
Configuration:
1.According to the LED heat dissipation performance, the heating is conducted quickly through the luminaire structure to guarantee the LED luminous efficiency and life span;
2.Special bracket design of luminaire to adjust the angle of lighting projection horizontally,easy for installation.
GB: According to CQC (China Quality Certification Center) and EMC (Electromagnetic Compatibility) standard luminaires are designed strictly.
Optics:
Adopted 4in1 (RGBW) LED be able to create the best uniformity of full white light range of color temperature (such as 6000K,5000K,4000K,3000K,2200K and colors light (such as water blue, sky blue, light purple, light green, amber, water red), and it is also good to achieve much better pure white light and color mixing lighting effect.
Control:
1.16.7 million lighting effects of RGB color changing, achieve synchronization, chasing, flowing light effects, DMX512 compatible;
2.Luminaires with the functions of testing and feedback of temperature and electrical parameters.
Application: Suitable for wall lighting such as park, plaza, commercial real estate
and building etc.
Luminaires shape | Strip |
---|---|
Glass material | Jade black |
LED quantity | 6、9、15、18 |
LED color (single color) | 4 in 1 red green blue 4000k(RGBWN)、4-in-1 RGBWH 5000k |
Power input | 36V DC |
Control | DMX512 high-power |
Installation | Bottom installation |
Cables outlet | Bottom outlet、Side face outlet |
Electricity Way | 直流 |
Way of connecting wires | Series power cable,with waterproof connector1 |
Specification of LED | 350mA |
Lamp length | 1000 |
LED Type | CREE XML |
